The S27 NAISH Jet HA foils are designed for advanced and semi-advanced foilers looking to push their performance levels in surf, SUP, Wing-surfer, and downwind foiling.
Recommended for: Expert Performance Foil Surfing/Downwind Foiling/Wing Foiling
What’s in the box?
- Stabilizer HA 220 (1040)
- Stabilizer HA 280 (1240)
- Stabilizer HA 280 (1400)
- Stabilizer HA 310 (1800 + 2140)
- 75 cm Mast
- 64 cm Fuselage
- 5 x 20 mm Torx Head Stainless Steel Screws (Connects Wings to Fuselage) = Superior torque + corrosion resistant
- 3 x 25 mm Torx Head Stainless Steel Screws (Connects Mast to Fuselage) = Superior torque + corrosion resistant
- 4 x 25 mm Torx Head Stainless Steel Screws and 4 x M6 Tab (Connects Standard Plate to Board) = Superior torque + corrosion resistant
- EVA Wing Covers
- Carry Case
New for this season is the 1040 and 2140, further expanding the HA range. The 1040 is fast, nimble, and great for high-speed foiling. Lighter riders will love the feel of this foil when wing foiling or surfing. These wings feature high aspect ratio planforms and proprietary thin section profiles — the result is maximum glide, excellent pumping, and improved top speed while still maintaining the excellent turning and control that defines the Jet range. To complement the high-end performance of these new wings, the complete foils feature a new high aspect stabilizer that emphasizes pumping ability and glide. Designed with a thinner profile and higher aspect ratio, they support the higher speed of the HA front wings while giving excellent response to rider input.
The 2140 pushes the envelope of flatwater pumping. This foil excels at low speeds or when wing foiling in light winds.
Features
- Naish Aluminum Masts are Available as Direct Connect as well as Deep Tuttle and Abracadabra Connection Systems
- Lightweight, Foam Filled Aircraft Grade, Triple Stringer Extruded Aluminum Mast with Bonded and Screwed Connections
- 100% Pre-preg 3K High Gloss Carbon Fiber Front Wing and Stabilizer
- CNC Precision Cut Lightweight Aluminum Fuselage with Corrosion Resistant Stainless Steel M6 Helicoils for the Front Wing and Stabilizer Connection
- Stainless Steel M6 Torx T30 Hardware for all Screwed Connections
Specification
| FRONT WING | ASPECT RATIO | WINGSPAN | PROJECTED SURFACE AREA | RIDER WEIGHT |
|---|---|---|---|---|
| Jet HA 1040 | 7.9 | 34.3″/87 cm | 161.2 in²/1040 cm² | Up to 85 kg |
| Jet HA 1240 | 7.2 | 37.2″/94.5 cm | 192.2 in²/1240 cm² | Up to 90 kg |
| Jet HA 1400 | 6.9 | 38.6″/98 cm | 217 in²/1400 cm² | Up to 100 kg |
| Jet HA 1800 | 5.6 | 39.4″/100 cm | 279 in²/1800 cm² | Up to 110 kg |
| Jet HA 2140 | 5.4 | 42.3″/107.5 cm | 379.7 in²/2140 cm² | Up to 120 kg |
