How to service your Lift Efoil Motor

Lip Seals and Oil Change

These instructions will walk you through the replacement of the two Lip seals and perform your own oil change.

Note: It will be easier to perform these repairs with the mast removed.

Step 1
If the Lift LCS is installed, remove the prop. For a conventional prop, remove the center bolt, then pull out the propeller and pin (the pin may fall out, make sure not to lose it). If the propeller is jammed, you may try to: a. lightly tap on it, b. soak it in water for about an hour, or, c. use a prop remover.



Step 2

Remove the four screws that connect the LCS base or shroud to the motor casing.  Slide out the LCS base or shroud.  Four replacement screws are provided.  Use NEW/provided Allen Wrenches to remove the screws.

EFS Oil change kit 5

Step 3
Remove the Rotary Seal from the shroud or LCS base.  Use a sharp object is required.  Replace with provided Lip Seal, open side facing motor.

EFS Oil change kit 3

Step 4
Use a sharp object to remove Lip Seal from motor.  Remove and replace the compression O-Ring.

EFS Oil change kit 4

Step 5
Remove the drain fill screw and replace the O Ring.  Tilt the motor with the screw hole facing downward. Without the seal and screw, the oil should drain easily; While the drain hole faces down, twist and rotate the motor housing in a circular motion to help the oil accumulate at the opening. If the oil appears very milky, clean it using brake cleaner. Use the straw attachment on the brake cleaner can to spray up the drain hole and help flush out any contaminants.

EFS Oil change kit 8

Step 6
Tilt the motor with the drain hole facing up.  Install the second Rotary Seal provided, open side facing prop.  Use syringe and thick needle provided to add oil to the motor.  You may need to use most or all of the oil.  The oil bottle provided contains slightly.  DO NOT OVERFILL.  If the oil reaches the top, remove about 5-10 ml using the syringe.

EFS Oil change kit 1

Step 7
Reassemble in reverse order.


Safe Use of the Efoil Solutions Propellers

FAILURE TO COMPLY WITH THESE WARNINGS MAY RESULT IN SERIOUS INJURIES.

  • Use of this Propeller and the sport of E-foiling involve inherent risks of injury or death. By using this product, you accept the risk of its use.
  • The Efoil Solutions propellers are for advanced Efoil users only and some may be used without the manufacturer propeller guard.  Use added caution.
  • Contact with rotating propeller may cause serious injury or death.  While the propeller is spinning, KEEP AWAY.
  • Turn off the remote and disconnect the battery from the Efoil before handling the propeller.
  • Always inspect the product before use.
  • Never ride at speeds that exceed your abilities.
  • Always wear protective gear.
  • Avoid wearing loose clothes that may get entangled with the propeller.
  • Never allow inexperienced riders to operate this product without proper training.
  • Do not allow children to operate this product.
